SCANSTA112VS/NOPB Texas Instruments - Yeehing Electronics

7-port multidrop IEEE 1149.1 (JTAG) multiplexer

Pricing (USD)

Quantity	Unit Price
1 — 99	12.684
100 — 249	11.079
250 — 999	8.543
1,000 +	5.35

The above prices are for reference only.

Specifications

Manufacturer	Texas Instruments
Product Category	Encoders, Decoders, Multiplexers & Demultiplexers
RoHS	Y
Product	Multiplexers
Number of Bits	32 bit
Propagation Delay Time	12 ns
Supply Voltage - Min	3 V
Supply Voltage - Max	3.6 V
Minimum Operating Temperature	- 40 C
Maximum Operating Temperature	+ 85 C
Mounting Style	SMD/SMT
Package / Case	TQFP-100
Packaging	Tray
Operating Temperature Range	- 40 C to + 85 C
Series	SCANSTA112
Brand	Texas Instruments
Development Kit	SCANSTA112EVK/NOPB
Moisture Sensitive	Yes
Product Type	Encoders, Decoders, Multiplexers & Demultiplexers
Factory Pack Quantity	90
Subcategory	Logic ICs
Unit Weight	0.023175 oz

For more information, please refer to datasheet

Documents

SCANSTA112VS/NOPB Datasheet

More Information

The SCANSTA112 extends the IEEE Std. 1149.1 test bus into a multidrop test bus environment. The advantage of a multidrop approach over a single serial scan chain is improved test throughput and the ability to remove a board from the system and retain test access to the remaining modules. Each SCANSTA112 supports up to 7 local IEEE1149.1 scan chains which can be accessed individually or combined serially.
