Texas Instruments
SN55451BJG
SN55451BJG
Regular price
$4.14 USD
Regular price
Sale price
$4.14 USD
Unit price
per
Couldn't load pickup availability
SN55451BJG Texas Instruments - Yeehing Electronics
Military 2-ch, 4.5-V to 5.5-V inverters
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 9.812 |
| 100 — 249 | 8.571 |
| 250 — 999 | 6.608 |
| 1,000 + | 4.14 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Buffers & Line Drivers |
| Number of Input Lines | 4 Input |
| Number of Output Lines | 2 Output |
| Supply Voltage - Max | 5.5 V |
| Supply Voltage - Min | 4.5 V |
| Minimum Operating Temperature | - 55 C |
| Maximum Operating Temperature | + 125 C |
| Mounting Style | Through Hole |
| Package / Case | CDIP-8 |
| Packaging | Tube |
| Operating Temperature Range | - 55 C to + 125 C |
| Output Type | Open Collector |
| Series | SN55451B |
| Brand | Texas Instruments |
| Logic Family | TTL |
| Logic Type | AND |
| Number of Channels | 2 Channel |
| High Level Output Current | 300 uA |
| Input Signal Type | TTL |
| Pd - Power Dissipation | 1.05 W |
| Product Type | Buffers & Line Drivers |
| Propagation Delay Time | 18 ns |
| Factory Pack Quantity | 50 |
| Subcategory | Logic ICs |
For more information, please refer to datasheet
Documents
| SN55451BJG Datasheet |
More Information
The SN5545xB and SN7545xB devices are dual-peripheral drivers designed for use in systems that employ TTL logic. This family is functionally interchangeable with and replaces the SN75450 family and the SN75450A family devices manufactured previously. The speed of the devices is equal to that of the SN75450 family, and the parts are designed to ensure freedom from latch-up. Diode-clamped inputs simplify circuit design.
