SN65LVDS302ZXH Texas Instruments - Yeehing Electronics

Programmable 27-bit display serial interface receiver

Pricing (USD)

Quantity	Unit Price
1 — 99	2.424
100 — 249	2.124
250 — 999	1.489
1,000 +	0.84

The above prices are for reference only.

Specifications

For more information, please refer to datasheet

Documents

SN65LVDS302ZXH Datasheet

More Information

The SN65LVDS302 receiver de-serializes FlatLink™3G compliant serial input data to 27 parallel data outputs. The SN65LVDS302 receiver contains one shift register to load 30 bits from 1, 2 or 3 serial inputs and latches the 24 pixel bits and 3 control bits out to the parallel CMOS outputs after checking the parity bit. If the parity check confirms correct parity, the Channel Parity Error (CPE) output remains low. If a parity error is detected, the CPE output generates a high pulse while the data output bus disregards the newly-received pixel. Instead, the last data word is held on the output bus for another clock cycle.
