SN65LVDS314RSKR Texas Instruments - Yeehing Electronics

Programmable 27-bit serial-to-parallel receiver

Pricing (USD)

Quantity	Unit Price
1 — 99	3.466
100 — 249	3.037
250 — 999	2.13
1,000 +	1.37

The above prices are for reference only.

Specifications

Manufacturer	Texas Instruments
Product Category	Serializers & Deserializers - Serdes
RoHS	Y
Minimum Operating Temperature	- 40 C
Maximum Operating Temperature	+ 85 C
Package / Case	VQFN-64
Packaging	Reel
Series	SN65LVDS314
Brand	Texas Instruments
Moisture Sensitive	Yes
Product Type	Serializers & Deserializers - Serdes
Factory Pack Quantity	2000
Subcategory	Interface ICs
Unit Weight	0.008021 oz

For more information, please refer to datasheet

Documents

SN65LVDS314RSKR Datasheet

More Information

The SN65LVDS314 receiver de-serializes FlatLink™3G compliant serial input data to 27 parallel data outputs. The SN65LVDS314 receiver contains one shift register to load 30 bits from 1, 2 or 3 serial inputs and latches the 24 pixel bits and 3 control bits out to the parallel CMOS outputs after checking the parity bit. If the parity check confirms correct parity, the Channel Parity Error (CPE) output remains low. If a parity error is detected, the CPE output generates a high pulse while the data output bus disregards the newly-received pixel. Instead, the last data word is held on the output bus for another clock cycle.
