SN74AUP1G02DPWR Texas Instruments - Yeehing Electronics
Single 2-input, 0.8-V to 3.6-V low power NOR gate
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 0.301 |
| 100 — 249 | 0.205 |
| 250 — 999 | 0.158 |
| 1,000 + | 0.06 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Logic Gates |
| RoHS | Y |
| Product | Single-Function Gate |
| Logic Function | NOR |
| Logic Family | AUP |
| Number of Gates | 1 Gate |
| Number of Input Lines | 2 Input |
| Number of Output Lines | 1 Output |
| High Level Output Current | - 4 mA |
| Low Level Output Current | 4 mA |
| Propagation Delay Time | 4.7 ns |
| Supply Voltage - Max | 3.6 V |
| Supply Voltage - Min | 0.8 V |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 85 C |
| Mounting Style | SMD/SMT |
| Package / Case | X2SON-4 |
| Packaging | Reel |
| Operating Temperature Range | - 40 C to + 85 C |
| Output Current | 20 mA |
| Output Voltage | 3.6 V |
| Series | SN74AUP1G02 |
| Brand | Texas Instruments |
| Logic Type | True |
| Product Type | Logic Gates |
| Factory Pack Quantity | 3000 |
| Subcategory | Logic ICs |
| Unit Weight | 0.000021 oz |
For more information, please refer to datasheet
Documents
| SN74AUP1G02DPWR Datasheet |
More Information
This single 2-input positive-NOR gate performs the Boolean function Y = A + B or Y = A × B in positive logic.
