SN74HC595BRWNR Texas Instruments - Yeehing Electronics
8-Bit Shift Registers With 3-State Output
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 0.287 |
| 100 — 249 | 0.195 |
| 250 — 999 | 0.151 |
| 1,000 + | 0.07 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Minimum Operating Temperature | -55 |
| Maximum Operating Temperature | 125 |
| Factory Pack Quantity | 2,000 |
| Package | Pins | X1QFN (RWN) | 16 |
For more information, please refer to datasheet
Documents
| SN74HC595BRWNR Datasheet |
More Information
The SN74HC595B devices contain an 8-bit, serial-in, parallel-out shift register that feeds an 8-bit D-type storage register. The storage register has parallel 3-state outputs. Separate clocks are provided for both the shift register and storage register. The shift register has a direct overriding clear (SRCLR) input, serial (SER) input, and serial outputs for cascading. When the output-enable (OE) input is high, the all outputs are in the high-impedance state except QH.
