SN74HCS595QBQBRQ1 Texas Instruments - Yeehing Electronics
Automotive 8-bit shift register with Schmitt-trigger inputs and 3-state output registers
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 0.476 |
| 100 — 249 | 0.324 |
| 250 — 999 | 0.25 |
| 1,000 + | 0.10 |
The above prices are for reference only.
Specifications
For more information, please refer to datasheet
Documents
| SN74HCS595QBQBRQ1 Datasheet |
More Information
The SN74HCS595-Q1 device contains an 8-bit, serial-in, parallel-out shift register that feeds an 8-bit D-type storage register. All inputs include Schmitt-trigger architecture, eliminating any erroneous data outputs due to slow-edged or noisy input signals. The storage register has parallel 3-state outputs. Separate clocks are provided for both the shift and storage register. The shift register has a direct overriding clear (SRCLR) input, serial (SER) input, and a serial output (QH) for cascading. When the output-enable (OE) input is high, the storage register outputs are in a high-impedance state. Internal register data and serial output (QH) are not impacted by the operation of the OE input.
