SN74LVTH126DGVR Texas Instruments - Yeehing Electronics
4-ch, 2.7-V to 3.6-V buffers with bus-hold, TTL-compatible CMOS inputs and 3-state outputs
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 0.459 |
| 100 — 249 | 0.312 |
| 250 — 999 | 0.241 |
| 1,000 + | 0.11 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Buffers & Line Drivers |
| RoHS | Y |
| Number of Input Lines | 4 Input |
| Number of Output Lines | 3 Output |
| Polarity | Non-Inverting |
| Supply Voltage - Max | 3.6 V |
| Supply Voltage - Min | 2.7 V |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 85 C |
| Mounting Style | SMD/SMT |
| Package / Case | TVSOP-14 |
| Packaging | Reel |
| Function | Buffer/Line Driver |
| Height | 1.05 mm |
| Length | 3.6 mm |
| Operating Temperature Range | - 40 C to + 85 C |
| Output Type | 3-State |
| Quiescent Current | 4.5 mA |
| Series | SN74LVTH126 |
| Technology | BiCMOS |
| Width | 4.4 mm |
| Brand | Texas Instruments |
| Logic Family | LVT |
| Logic Type | Quadruple Bus Buffer |
| Number of Channels | 4 |
| Supply Current - Max | 7000 uA |
| High Level Output Current | - 32 mA |
| Input Signal Type | Single-Ended |
| Low Level Output Current | 64 mA |
| Operating Supply Current | 7 uA |
| Operating Supply Voltage | 3.3 V |
| Product Type | Buffers & Line Drivers |
| Propagation Delay Time | 2.4 ns at 3.3 V |
| Factory Pack Quantity | 2000 |
| Subcategory | Logic ICs |
| Unit Weight | 0.001474 oz |
For more information, please refer to datasheet
Documents
| SN74LVTH126DGVR Datasheet |
More Information
These bus buffers are designed specifically for low-voltage (3.3-V) VCC operation, but with the capability to provide a TTL interface to a 5-V system environment.
