SN75451BPS Texas Instruments - Yeehing Electronics

30-V Dual output driver with AND logic inputs

Pricing (USD)

Quantity	Unit Price
1 — 99	0.613
100 — 249	0.471
250 — 999	0.347
1,000 +	0.17

The above prices are for reference only.

Specifications

Manufacturer	Toshiba
Product Category	Buffers & Line Drivers
RoHS	Y
Number of Input Lines	8 Input
Number of Output Lines	8 Output
Polarity	Inverting
Supply Voltage - Max	3.6 V
Supply Voltage - Min	1.65 V
Minimum Operating Temperature	- 40 C
Maximum Operating Temperature	+ 85 C
Mounting Style	SMD/SMT
Package / Case	TSSOP-20
Packaging	Reel
Output Type	3-State
Series	74LCX240
Brand	Toshiba
Logic Family	LCX
Logic Type	CMOS
Number of Channels	8 Channel
High Level Output Current	- 24 mA
Low Level Output Current	24 mA
Operating Supply Current	10 uA
Pd - Power Dissipation	180 mW
Product Type	Buffers & Line Drivers
Propagation Delay Time	6.5 ns at 3.3 V
Factory Pack Quantity	2500
Subcategory	Logic ICs
Part # Aliases	74LCX240FT
Unit Weight	0.006737 oz

For more information, please refer to datasheet

Documents

SN75451BPS Datasheet

More Information

The SN5545xB and SN7545xB devices are dual-peripheral drivers designed for use in systems that employ TTL logic. This family is functionally interchangeable with and replaces the SN75450 family and the SN75450A family devices manufactured previously. The speed of the devices is equal to that of the SN75450 family, and the parts are designed to ensure freedom from latch-up. Diode-clamped inputs simplify circuit design.
