SNJ54ALS646JT Texas Instruments - Yeehing Electronics

Octal Registered Bus Transceivers with 3-State Outputs

Pricing (USD)

Quantity	Unit Price
1 — 99	48.128
100 — 249	42.78
250 — 999	35.168
1,000 +	22.02

The above prices are for reference only.

Specifications

For more information, please refer to datasheet

Documents

SNJ54ALS646JT Datasheet

More Information

These devices consist of bus-transceiver circuits with 3-state or open-collector outputs, D-type flip-flops, and control circuitry arranged for multiplexed transmission of data directly from the data bus or from the internal storage registers. Data on the A or B bus is clocked into the registers on the low-to-high transition of the appropriate clock (CLKAB or CLKBA) input. Figure 1 illustrates the four fundamental bus-management functions that can be performed with the octal bus transceivers and registers.
