SNJ54LS09W Texas Instruments - Yeehing Electronics

Military 4-ch, 2-input, 4.5-V to 5.5-V bipolar AND gates with open-collector outputs

Pricing (USD)

Quantity	Unit Price
1 — 99	24.351
100 — 249	21.27
250 — 999	16.4
1,000 +	10.27

The above prices are for reference only.

Specifications

For more information, please refer to datasheet

Documents

SNJ54LS09W Datasheet

More Information

These devices contain four independent 2-input AND gates. The open-collector outputs require pull-up resistors to perform correctly. They may be connected to other open-collector outputs to implement active-low wired-OR or active-high wired-AND functions. Open-collector devices are often used to generate higher VOH levels.
