SNJ54LS593J Texas Instruments - Yeehing Electronics

8-Bit Binary Counters With Input Registers

Pricing (USD)

Quantity	Unit Price
1 — 99	51.156
100 — 249	45.472
250 — 999	37.38
1,000 +	23.40

The above prices are for reference only.

Specifications

For more information, please refer to datasheet

Documents

SNJ54LS593J Datasheet

More Information

The 'LS592 comes in a 16-pin package and consists of a parallel input, 8-bit storage register feeding an 8-bit binary counter. Both the register and the counter have individual positive-edge-triggered clocks. In addition, the counter has direct load and clear functions. A low-going RCO pulse will be obtained when the counter reaches the hex word FF. Expansion is easily accomplished for two stages by connecting RCO of the first stage to CCKEN of the second stage. Cascading for larger count chains can be accomplished by connecting RCO of each stage to CCK of the following stage.
