TAS5701PAPR Texas Instruments - Yeehing Electronics
20-W stereo, 0- to 21-V supply, digital input, open loop Class-D audio amplifier w/ H/W control
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 8.924 |
| 100 — 249 | 7.275 |
| 250 — 999 | 5.718 |
| 1,000 + | 3.39 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Audio Amplifiers |
| RoHS | Y |
| Series | TAS5701 |
| Product | Audio Amplifiers |
| Class | Class-D |
| Output Power | 20 W |
| Mounting Style | SMD/SMT |
| Type | 3-Channel Stereo |
| Package / Case | HTQFP-64 |
| Audio - Load Impedance | 8 Ohms |
| THD plus Noise | 0.1 % |
| Minimum Operating Temperature | 0 C |
| Maximum Operating Temperature | + 85 C |
| Packaging | Reel |
| Description/Function | Speaker |
| Height | 1 mm |
| Input Type | Single |
| Length | 10 mm |
| Output Current | 20 mA |
| Output Type | 3-Channel Stereo |
| Supply Type | Quint |
| Width | 10 mm |
| Brand | Texas Instruments |
| Number of Channels | 3 Channel |
| Supply Current - Max | 80 mA, 60 mA, 10 mA |
| Dual Supply Voltage | 3 V, 5 V, 9 V, 12 V, 15 V, 18 V |
| Ib - Input Bias Current | - |
| Maximum Dual Supply Voltage | 3.6 V, 13.2 V, 21 V |
| Minimum Dual Supply Voltage | 0 V, 3 V, 10.8 V |
| Moisture Sensitive | Yes |
| Operating Supply Current | 65 mA, 30 mA, 5 mA |
| Output Signal Type | Differential |
| Pd - Power Dissipation | 600 mW |
| Product Type | Audio Amplifiers |
| PSRR - Power Supply Rejection Ratio | 60 dB |
| Factory Pack Quantity | 1000 |
| Subcategory | Audio ICs |
| Unit Weight | 0.009108 oz |
For more information, please refer to datasheet
Documents
| TAS5701PAPR Datasheet |
More Information
