TCA9554DBR Texas Instruments - Yeehing Electronics

8-bit 1.65- to 5.5-V I2C/SMBus I/O expander with interrupt, weak pull-up & config registers

Pricing (USD)

Quantity	Unit Price
1 — 99	1.129
100 — 249	0.868
250 — 999	0.639
1,000 +	1.03

The above prices are for reference only.

Specifications

Manufacturer	Texas Instruments
Minimum Operating Temperature	-40
Maximum Operating Temperature	85
Factory Pack Quantity	2,000
Package | Pins	SSOP (DB) | 16

For more information, please refer to datasheet

Documents

TCA9554DBR Datasheet

More Information

The TCA9554 is a 16-pin device that provides 8 bits of general purpose parallel input and output (I/O) expansion for the two-line bidirectional I2C bus (or SMBus) protocol. The device can operate with a power supply voltage ranging from 1.65 V to 5.5 V. The device supports both 100-kHz (Standard-mode) and 400-kHz (Fast-mode) clock frequencies. I/O expanders such as the TCA9554 provide a simple solution when additional I/Os are needed for switches, sensors, push-buttons, LEDs, fans, and other similar devices.
