Description
THS4531AIRUNT Texas Instruments - Yeehing Electronics
Ultra Low Power, RRO, Fully-Differential Amplifier
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 2.889 |
| 100 — 249 | 2.531 |
| 250 — 999 | 1.775 |
| 1,000 + | 1.14 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Differential Amplifiers |
| RoHS | Y |
| Series | THS4531A |
| Number of Channels | 1 Channel |
| GBP - Gain Bandwidth Product | 27 MHz |
| SR - Slew Rate | 220 V/us |
| CMRR - Common Mode Rejection Ratio | 90 dB to 116 dB |
| Vos - Input Offset Voltage | 0.4 mV |
| Supply Voltage - Max | 5.5 V |
| Supply Voltage - Min | 2.5 V |
| Operating Supply Current | 250 uA |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 125 C |
| Packaging | Reel |
| Features | Small Size, Shutdown |
| Input Type | Rail-to-Rail |
| Output Type | Rail-to-Rail |
| Product | Differential Amplifiers |
| Brand | Texas Instruments |
| Shutdown | No Shutdown |
| Moisture Sensitive | Yes |
| Product Type | Differential Amplifiers |
| Factory Pack Quantity | 250 |
| Subcategory | Amplifier ICs |
| Unit Weight | 0.000317 oz |
For more information, please refer to datasheet
Documents
| THS4531AIRUNT Datasheet |
More Information
The THS4531A device is a low-power, fully differential amplifier with input common-mode range below the negative rail and rail-to-rail output. The device is designed for low-power data acquisition systems and high-density applications where power consumption and dissipation is critical.
