Texas Instruments
THS6214IRHFT
THS6214IRHFT
Regular price
$2.88 USD
Regular price
Sale price
$2.88 USD
Unit price
per
Couldn't load pickup availability
THS6214IRHFT Texas Instruments - Yeehing Electronics
High Speed, Dual Port, Differential DSL Line Driver Amplifier
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 7.272 |
| 100 — 249 | 6.372 |
| 250 — 999 | 4.468 |
| 1,000 + | 2.88 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | High Speed Operational Amplifiers |
| RoHS | Y |
| Series | THS6214 |
| Number of Channels | 2 Channel |
| SR - Slew Rate | 3.8 kV/us |
| CMRR - Common Mode Rejection Ratio | 53 dB to 65 dB |
| Vos - Input Offset Voltage | 50 mV |
| Supply Voltage - Max | 28 V |
| Supply Voltage - Min | 10 V |
| Operating Supply Current | 21 mA |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 85 C |
| Package / Case | VQFN-24 |
| Packaging | Reel |
| Features | Adj Current Limit |
| Output Type | Differential |
| Brand | Texas Instruments |
| Moisture Sensitive | Yes |
| Operating Supply Voltage | 12 V, 15 V, 18 V, 24 V |
| Product Type | Op Amps - High Speed Operational Amplifiers |
| Factory Pack Quantity | 250 |
| Subcategory | Amplifier ICs |
| Unit Weight | 0.001926 oz |
For more information, please refer to datasheet
Documents
| THS6214IRHFT Datasheet |
More Information
The THS6214 is a dual-port, current-feedback architecture, differential line driver amplifier system ideal for xDSL systems. The device is targeted for use in very-high-bit-rate digital subscriber line 2 (VDSL2) line driver systems that enable greater than 14.5-dBm line power, supporting the G.993.2 VDSL2 17a profile. The device is also fast enough to support central-office transmissions of 14.5-dBm line power up to 30 MHz. The device is also targeted for use as a broadband or wideband power line communications (PLC) amplifier for line driver applications.
