THS9000DRWT


YeeHing #: Y013-THS9000DRWT
Inventory: 7200

Feel free to reach out to us for more information.
Click the button below to unveil exclusive discounts and delightful surprises.

Description

THS9000DRWT Texas Instruments - Yeehing Electronics

50 MHz to 750 MHz Cascadable Amplifier

Pricing (USD)

Quantity Unit Price
1 — 99 1.478
100 — 249 1.221
250 — 999 0.877
1,000 + 0.46

The above prices are for reference only.

Specifications

Manufacturer Texas Instruments
Product Category RF Amplifier
RoHS Y
Mounting Style SMD/SMT
Package / Case VSON-6
Type Cascadable Amplifier
Operating Frequency 50 MHz to 400 MHz
P1dB - Compression Point 20.6 dBm
Gain 15.6 dB
Operating Supply Voltage 5 V
NF - Noise Figure 4 dB
Test Frequency 350 MHz
OIP3 - Third Order Intercept 35 dBm
Operating Supply Current 100 mA
Minimum Operating Temperature - 40 C
Maximum Operating Temperature + 85 C
Series THS9000
Packaging Reel
Bandwidth 400 MHz
Brand Texas Instruments
Number of Channels 1 Channel
Development Kit THS9000EVM
Moisture Sensitive Yes
Pd - Power Dissipation 1.1 W
Product Type RF Amplifier
Factory Pack Quantity 250
Subcategory Wireless & RF Integrated Circuits
Supply Voltage - Max 5.5 V
Supply Voltage - Min 3 V
Unit Weight 0.000907 oz

For more information, please refer to datasheet

Documents

THS9000DRWT Datasheet

More Information

The THS9000 is a medium power, cascadeable, gain block optimized for high IF frequencies. The amplifier incorporates internal impedance matching to 50 Ω. The part mounted on the standard EVM achieves greater than 15-dB input and output return loss from 50 MHz to 325 MHz with VS = 5 V, R(BIAS) = 237 Ω, L(COL) = 470 nH. Design requires only two dc-blocking capacitors, one power-supply bypass capacitor, one RF choke, and one bias resistor.
