Texas Instruments
TIOS1013DMWT
TIOS1013DMWT
Regular price
$0.92 USD
Regular price
Sale price
$0.92 USD
Unit price
per
Couldn't load pickup availability
TIOS1013DMWT Texas Instruments - Yeehing Electronics
Digital sensor output driver with integrated surge protection and 3.3-V LDO output
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 2.93 |
| 100 — 249 | 2.42 |
| 250 — 999 | 1.738 |
| 1,000 + | 0.92 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Sensor Interface |
| RoHS | Y |
| Type | Digital Output Switch |
| Interface Type | - |
| Supply Voltage - Max | 36 V |
| Supply Voltage - Min | 7 V |
| Operating Supply Current | 2 mA |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 125 C |
| Mounting Style | SMD/SMT |
| Package / Case | VSON-10 |
| Packaging | Reel |
| Features | Reverse polarity protection, Configurable current limiter |
| Output Current | 350 mA |
| Output Voltage | 3.3 V |
| Product | Digital Sensor Output Drivers |
| Series | TIOS101 |
| Brand | Texas Instruments |
| Number of Channels | 1 Channel |
| Moisture Sensitive | Yes |
| Operating Supply Voltage | 24 V |
| Product Type | Sensor Interface |
| Factory Pack Quantity | 250 |
| Subcategory | Interface ICs |
| Unit Weight | 0.000670 oz |
For more information, please refer to datasheet
Documents
| TIOS1013DMWT Datasheet |
More Information
The TIOS101(x) devices are configurable as high-side, low-side or push-pull drivers. These devices are capable of withstanding up to 1.2 kV (500 Ω) of IEC 61000-4-5 surge and feature integrated reverse polarity protection.
