TLC5947DAP Texas Instruments - Yeehing Electronics

24-channel, 12-bit PWM LED driver with internal Oscillator

Pricing (USD)

Quantity	Unit Price
1 — 99	3.205
100 — 249	2.613
250 — 999	2.054
1,000 +	1.03

The above prices are for reference only.

Specifications

Manufacturer	Texas Instruments
Product Category	LED Lighting Drivers
RoHS	Y
Number of Channels	24 Channel
Output Current	30 mA
Input Voltage	3 V to 5.5 V
Operating Frequency	30 MHz
Supply Current - Max	90 mA
Minimum Operating Temperature	- 40 C
Maximum Operating Temperature	+ 85 C
Mounting Style	SMD/SMT
Package / Case	HTSSOP-32
Series	TLC5947
Packaging	Reel
Features	Internal GS Clock, PWM LED Driver, Thermal Shutdown
Operating Temperature Range	- 40 C to + 85 C
Brand	Texas Instruments
High Level Output Current	- 3 mA
Low Level Output Current	3 mA
Moisture Sensitive	Yes
Operating Supply Voltage	3 V to 5.5 V
Pd - Power Dissipation	5318 mW
Product Type	LED Lighting Drivers
Factory Pack Quantity	2000
Subcategory	Driver ICs
Unit Weight	0.006388 oz

For more information, please refer to datasheet

Documents

TLC5947DAP Datasheet

More Information

The TLC5947 is a 24-channel, constant-current sink LED driver. Each channel is individually adjustable with 4096 pulse-width modulated (PWM) steps. PWM control is repeated automatically with the programmed grayscale (GS) data. GS data are written via a serial interface port. The current value of all 24 channels is set by a single external resistor.
