TLC5958RTQT Texas Instruments - Yeehing Electronics
48 channel, 16 bit ES-PWM, LED driver with pre-charge FET, LED open detection and 48k bit memory
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 5.254 |
| 100 — 249 | 4.589 |
| 250 — 999 | 3.538 |
| 1,000 + | 2.22 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | LED Display Drivers |
| RoHS | Y |
| Series | TLC5958 |
| Mounting Style | SMD/SMT |
| Package / Case | QFN-56 |
| Operating Supply Voltage | 3 V to 5.5 V |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 85 C |
| Packaging | Reel |
| Features | Error Flag, Fault Detection, LED Open/Short Detection |
| Operating Temperature Range | - 40 C to + 85 C |
| Brand | Texas Instruments |
| Moisture Sensitive | Yes |
| Product Type | LED Display Drivers |
| Factory Pack Quantity | 250 |
| Subcategory | Driver ICs |
| Unit Weight | 0.007055 oz |
For more information, please refer to datasheet
Documents
| TLC5958RTQT Datasheet |
More Information
The TLC5958 is a 48 channels constant-current sink driver for multiplexing system with 1 to 32 duty ratio. Each channel has an individually-adjustable, 65536-step, pulse width modulation (PWM) grayscale (GS).
