Texas Instruments
TLK1211RCP
TLK1211RCP
Regular price
$4.25 USD
Regular price
Sale price
$4.25 USD
Unit price
per
Couldn't load pickup availability
TLK1211RCP Texas Instruments - Yeehing Electronics
Gigabit Ethernet SerDes for PON
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 10.08 |
| 100 — 249 | 8.804 |
| 250 — 999 | 6.788 |
| 1,000 + | 4.25 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Ethernet ICs |
| RoHS | Y |
| Series | TLK1211 |
| Product | Ethernet Transceivers |
| Number of Transceivers | 1 Transceiver |
| Data Rate | 0.6 Gb/s |
| Operating Supply Voltage | 2.5 V |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 85 C |
| Mounting Style | SMD/SMT |
| Package / Case | HVQFP-64 |
| Packaging | Tray |
| Height | 0.8 mm |
| Length | 10 mm |
| Width | 10 mm |
| Brand | Texas Instruments |
| Supply Current - Max | 113 mA |
| Moisture Sensitive | Yes |
| Product Type | Ethernet ICs |
| Factory Pack Quantity | 160 |
| Subcategory | Communication & Networking ICs |
| Supply Voltage - Max | 2.7 V |
| Supply Voltage - Min | 2.3 V |
| Unit Weight | 0.008004 oz |
For more information, please refer to datasheet
Documents
| TLK1211RCP Datasheet |
More Information
The TLK1211RCP gigabit ethernet transceiver provides for ultrahigh-speed, full-duplex, point-to-point data transmissions. This device is based on the timing requirements of the 10-bit interface specification by the IEEE 802.3 gigabit ethernet specification and is also compliant with the ANSI X3.230-1994 (FC-PH) fibre channel standard. The device supports data rates from 0.6 Gbps to 1.3 Gbps.
