TLV809L30DBVR


YeeHing #: Y012-TLV809L30DBVR
Inventory: 3000

Feel free to reach out to us for more information.
Click the button below to unveil exclusive discounts and delightful surprises.

Description

TLV809L30DBVR Texas Instruments - Yeehing Electronics

3-pin voltage supervisor (reset IC) with active-low, push-pull reset

Pricing (USD)

Quantity Unit Price
1 — 99 0.591
100 — 249 0.402
250 — 999 0.31
1,000 + 0.12

The above prices are for reference only.

Specifications

Manufacturer Texas Instruments
Product Category Supervisory Circuits
RoHS Y
Type Voltage Supervisory
Mounting Style SMD/SMT
Package / Case SOT-23-3
Threshold Voltage 2.64 V
Number of Inputs Monitored 1 Input
Output Type Active-low,Push-pull
Manual Reset No Manual Reset
Watchdog Timers No Watchdog
Battery Backup Switching No Backup
Reset Delay Time 200 ms
Supply Voltage - Max 6 V
Minimum Operating Temperature - 40 C
Maximum Operating Temperature + 85 C
Series TLV809L30
Packaging Reel
Operating Temperature Range - 40 C to + 85 C
Output Current 5 mA
Brand Texas Instruments
Undervoltage Threshold 2.64 V
Operating Supply Current 9 uA
Product Type Supervisory Circuits
Factory Pack Quantity 3000
Subcategory PMIC - Power Management ICs
Supply Voltage - Min 2 V
Unit Weight 0.000282 oz

For more information, please refer to datasheet

Documents

TLV809L30DBVR Datasheet

More Information

The TLV809 family of supervisory circuits provides circuit initialization and timing supervision, primarily for digital signal processors (DSPs) and processor-based systems. The newer TLV809E device is a pin-to-pin compatible alternative.
