TPA0233DGQ Texas Instruments - Yeehing Electronics
2-W, mono, analog input Class-AB audio amplifier with headphone amplfier & low supply current
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 3.157 |
| 100 — 249 | 2.767 |
| 250 — 999 | 1.94 |
| 1,000 + | 1.09 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Audio Amplifiers |
| RoHS | Y |
| Series | TPA0233 |
| Product | Audio Amplifiers |
| Class | Class-AB |
| Output Power | 2 W |
| Mounting Style | SMD/SMT |
| Type | 1-Channel Mono or 2-Channel Stereo |
| Package / Case | MSOP-PowerPad-10 |
| Audio - Load Impedance | 4 Ohms |
| THD plus Noise | 0.3 % |
| Supply Voltage - Max | 5.5 V |
| Supply Voltage - Min | 2.5 V |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 125 C |
| Packaging | Reel |
| Description/Function | Headphone/Speaker |
| Height | 1.02 mm |
| Input Type | Analog |
| Length | 3 mm |
| Output Type | 1-Channel Mono, 2-Channel Stereo |
| Supply Type | Single |
| Width | 3 mm |
| Brand | Texas Instruments |
| Number of Channels | 1 Channel |
| Supply Current - Max | 7 mA |
| Operating Supply Current | 4 mA |
| Operating Supply Voltage | 2.5 V to 5.5 V |
| Output Signal Type | Differential, Single |
| Pd - Power Dissipation | 2140 mW |
| Product Type | Audio Amplifiers |
| PSRR - Power Supply Rejection Ratio | 58 dB |
| Factory Pack Quantity | 2500 |
| Subcategory | Audio ICs |
| Unit Weight | 0.000663 oz |
For more information, please refer to datasheet
Documents
| TPA0233DGQ Datasheet |
More Information
The TPA0233 is a 2-W mono bridge-tied-load (BTL) amplifier designed to drive speakers with as low as 4- speaker.
