TPD12S015YFFR Texas Instruments - Yeehing Electronics
HDMI companion chip with step-up Con-Verter, I2C level shifter, and high-speed ESD clamps
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 1.496 |
| 100 — 249 | 1.236 |
| 250 — 999 | 0.888 |
| 1,000 + | 0.04 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Interface - Specialized |
| RoHS | Y |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 85 C |
| Package / Case | DSBGA-28 |
| Packaging | Reel |
| Series | TPD12S015 |
| Brand | Texas Instruments |
| Product Type | Interface - Specialized |
| Factory Pack Quantity | 3000 |
| Subcategory | Interface ICs |
For more information, please refer to datasheet
Documents
| TPD12S015YFFR Datasheet |
More Information
The TPD12S015 device is an integrated HDMI ESD solution. The device pin mapping matches the HDMI Type C and Type D connector with four differential pairs. This device offers eight low-capacitance ESD clamps, allowing HDMI 1.3 or 1.4 data rates. The integrated ESD clamps and resistors provide good matching between each differential signal pair, which allows an advantage over discrete ESD clamp solutions where variations between ESD clamps degrade the differential signal quality.
