TPD5S115YFFR Texas Instruments - Yeehing Electronics
HDMI companion chip with step-Up DC-DC Con-Verter, level shifter, and ESD clamp
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 0.911 |
| 100 — 249 | 0.701 |
| 250 — 999 | 0.516 |
| 1,000 + | 0.26 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Interface - Specialized |
| RoHS | Y |
| Type | HDMI Interface |
| Operating Supply Voltage | 3.6 V |
| Operating Supply Current | 15 uA |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 85 C |
| Mounting Style | SMD/SMT |
| Package / Case | DSBGA-16 |
| Packaging | Reel |
| Series | TPD5S115 |
| Brand | Texas Instruments |
| Product Type | Interface - Specialized |
| Factory Pack Quantity | 3000 |
| Subcategory | Interface ICs |
| Supply Voltage - Max | 3.6 V |
| Unit Weight | 0.000123 oz |
For more information, please refer to datasheet
Documents
| TPD5S115YFFR Datasheet |
More Information
The TPD5S115 device is an integrated HDMI companion chip solution. The device provides a regulated 5-V output (5VOUT) for sourcing the HDMI power line. The regulated 5-V output supplies up to 55 mA to the HDMI receiver with a current limiting function. The TPD5S115 features two control signals: EN and LS_OE. The control of 5VOUT and the hot plug detect (HPD) circuitry is independent of the LS_OE control signal and is controlled by the EN pin. The EN pin allows the detection scheme (5VOUT + HPD) to be active before turning on the whole HDMI link. The LS_OE activates the internal LDO, CEC, SCL, and SDA buffers only when EN is also activated. This dual stage enable scheme ensures optimized power saving for portable applications.
