TPS2060DGNR Texas Instruments - Yeehing Electronics
2-ch, 1.5A loading, 2.7-5.5V, 70mΩ USB power switch, active-low, reverse blocking
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 1.77 |
| 100 — 249 | 1.462 |
| 250 — 999 | 1.05 |
| 1,000 + | 0.55 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Power Switch ICs - Power Distribution |
| RoHS | Y |
| Type | High Side |
| Number of Outputs | 2 Output |
| Output Current | 1.5 A |
| Current Limit | 2.1 A |
| On Resistance - Max | 70 mOhms |
| Operating Supply Voltage | 2.7 V to 5.5 V |
| Supply Voltage - Min | 2.7 V |
| Supply Voltage - Max | 5.5 V |
| Minimum Operating Temperature | 0 C |
| Maximum Operating Temperature | + 70 C |
| Mounting Style | SMD/SMT |
| Package / Case | MSOP-PowerPad-8 |
| Series | TPS2060 |
| Packaging | Reel |
| Product | USB Power Switches |
| Brand | Texas Instruments |
| Product Type | Power Switch ICs - Power Distribution |
| Factory Pack Quantity | 2500 |
| Subcategory | Switch ICs |
| Unit Weight | 0.000861 oz |
For more information, please refer to datasheet
Documents
| TPS2060DGNR Datasheet |
More Information
The TPS206x power-distribution switches are intended for applications where heavy capacitive loads and short-circuits are likely to be encountered. This device incorporates 70-mΩ N-channel MOSFET power switches for power-distribution systems that require single or dual power switches in a single package. Each switch is controlled by a logic enable input. Gate drive is provided by an internal charge pump designed to control the power-switch rise times and fall times to minimize current surges during switching. The charge pump requires no external components and allows operation from supplies as low as 2.7 V.
