TPS53624RHAT Texas Instruments - Yeehing Electronics

Dual Phase D-CAP Buck Regulator with 8-Bit VID

Pricing (USD)

Quantity	Unit Price
1 — 99	3.87
100 — 249	3.391
250 — 999	2.378
1,000 +	1.34

The above prices are for reference only.

Specifications

Manufacturer	Texas Instruments
Product Category	Switching Controllers
RoHS	Y
Number of Outputs	1 Output
Switching Frequency	500 kHz
Input Voltage	3 V to 28 V
Output Voltage	1.7 V
Output Current	50 A
Minimum Operating Temperature	- 40 C
Maximum Operating Temperature	+ 125 C
Mounting Style	SMD/SMT
Package / Case	VQFN-40
Packaging	Reel
Operating Temperature Range	- 40 C to + 125 C
Series	TPS53624
Brand	Texas Instruments
Moisture Sensitive	Yes
Operating Supply Current	4 mA
Product Type	Switching Controllers
Factory Pack Quantity	250
Subcategory	PMIC - Power Management ICs
Unit Weight	0.003668 oz

For more information, please refer to datasheet

Documents

TPS53624RHAT Datasheet

More Information

The TPS53624 is a dual-phase step down controller with integrated gate drivers. The PCNT pin enables operation in dual or single-phase mode to optimize efficiency depending on the load requirements. Advanced control features such as D-CAP+™ architecture and OSR provides fast transient response with low output capacitance. The DAC supports VID-on-the-fly to optimize the output voltage to the operating state of the system to reduce quiescent power. The auto-skip feature of the TPS53624 optimizes light-load efficiency in single phase operation. System management features include adjustable thermal monitor input and output (THRM, THAL), output current monitoring (IMON), and complimentary power good signals (PG and PGD). Adjustable control of the output voltage slew rate and voltage positioning are provided. In addition, the TPS53624 includes two high-current FET gate drivers to drive high and low side N-channel FETs with exceptionally high speed and low switching loss. All logic input and output pins have flexible LV input and output thresholds that enable interface with logic voltages from 1 V to 3.6 V.
