TPS56C20PWPR Texas Instruments - Yeehing Electronics
4.5-V to 17-V, 12-A synchronous buck converter with voltage scaling
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 3.998 |
| 100 — 249 | 3.26 |
| 250 — 999 | 2.562 |
| 1,000 + | 1.52 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Switching Voltage Regulators |
| RoHS | Y |
| Mounting Style | SMD/SMT |
| Package / Case | HTSSOP-24 |
| Output Voltage | 0.6 V to 1.87 V |
| Output Current | 12 A |
| Number of Outputs | 1 Output |
| Input Voltage MAX | 17 V |
| Topology | Buck |
| Input Voltage MIN | 4.5 V |
| Switching Frequency | 500 kHz |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 85 C |
| Series | TPS56C20 |
| Packaging | Reel |
| Input Voltage | 4.5 V to 17 V |
| Operating Temperature Range | - 40 C to + 85 C |
| Product | Switching Regulators |
| Type | Synchronous Step-Down Regulator |
| Brand | Texas Instruments |
| Moisture Sensitive | Yes |
| Operating Supply Current | 920 uA |
| Product Type | Switching Voltage Regulators |
| Factory Pack Quantity | 2000 |
| Subcategory | PMIC - Power Management ICs |
| Unit Weight | 0.038731 oz |
For more information, please refer to datasheet
Documents
| TPS56C20PWPR Datasheet |
More Information
The TPS56X20 is a synchronous DC-DC converter IC (integrated circuit) with a voltage scaling control to power up micro-processors (MCUs) requiring core voltage (VCORE) tune-ups. After the initial power-up, the output voltage can be programmed/scaled by VID codes sent over an I2C compatible bus.
