TPS61093DSKT Texas Instruments - Yeehing Electronics
Low Input, 20V/1.1A Step-Up DC/DC Converter with Integrated Power Diode and Input/Output Isolation
Pricing (USD)
Quantity | Unit Price |
1 — 99 | 1.84 |
100 — 249 | 1.612 |
250 — 999 | 1.131 |
1,000 + | 0.55 |
The above prices are for reference only.
Specifications
Manufacturer | Texas Instruments |
Product Category | Switching Voltage Regulators |
RoHS | Y |
Mounting Style | SMD/SMT |
Package / Case | WSON-10 |
Output Voltage | 17 V |
Output Current | 1.1 A |
Number of Outputs | 1 Output |
Input Voltage MAX | 6 V |
Topology | Boost |
Input Voltage MIN | 1.6 V |
Switching Frequency | 1.2 MHz |
Minimum Operating Temperature | - 40 C |
Maximum Operating Temperature | + 85 C |
Series | TPS61093 |
Packaging | Reel |
Input Voltage | 1.6 V to 6 V |
Operating Temperature Range | - 40 C to + 85 C |
Product | Voltage Regulators |
Type | Voltage Converter |
Brand | Texas Instruments |
Development Kit | TPS61093EVM-519 |
Product Type | Switching Voltage Regulators |
Factory Pack Quantity | 250 |
Subcategory | PMIC - Power Management ICs |
Unit Weight | 0.000494 oz |
For more information, please refer to datasheet
Documents
TPS61093DSKT Datasheet |
More Information
The TPS61093 is a 1.2-MHz, fixed-frequency boost converter designed for high integration and high reliability. The IC integrates a 20-V power switch, input/output isolation switch, and power diode. When the output current exceeds the overload limit, the isolation switch of the IC opens up to disconnect the output from the input, thus protecting the IC and the input supply. The isolation switch also disconnects the output from the input during shutdown to minimize leakage current. When the IC is shut down, the output capacitor is discharged to a low voltage level by internal diodes. Other protection features include 1.1-A peak overcurrent protection (OCP) at each cycle, output overvoltage protection (OVP), thermal shutdown, and undervoltage lockout (UVLO).
