TPS61093QDSKRQ1 Texas Instruments - Yeehing Electronics
Automotive, 6-VIN, 17-VOUT, 1.1-A boost converter with integrated power diode, AEC-Q100 qualified
Pricing (USD)
Quantity | Unit Price |
1 — 99 | 2.769 |
100 — 249 | 2.427 |
250 — 999 | 1.701 |
1,000 + | 0.78 |
The above prices are for reference only.
Specifications
Manufacturer | Texas Instruments |
Product Category | Switching Voltage Regulators |
RoHS | Y |
Mounting Style | SMD/SMT |
Package / Case | SON-10 |
Output Voltage | 17 V |
Output Current | 1.1 A |
Number of Outputs | 1 Output |
Input Voltage MAX | 6 V |
Topology | Boost |
Input Voltage MIN | 1.6 V |
Switching Frequency | 1.2 MHz |
Minimum Operating Temperature | - 40 C |
Maximum Operating Temperature | + 125 C |
Qualification | AEC-Q100 |
Series | TPS61093-Q1 |
Packaging | Reel |
Input Voltage | 1.6 V to 6 V |
Operating Temperature Range | - 40 C to + 125 C |
Type | Low Input Boost Converter With integrated Power Diode and Input/Output Isolation |
Brand | Texas Instruments |
Shutdown | Shutdown |
Operating Supply Current | 900 uA |
Product Type | Switching Voltage Regulators |
Factory Pack Quantity | 3000 |
Subcategory | PMIC - Power Management ICs |
Supply Voltage - Min | 1.6 V |
Unit Weight | 0.000921 oz |
For more information, please refer to datasheet
Documents
TPS61093QDSKRQ1 Datasheet |
More Information
The TPS61093-Q1 is a 1.2-MHz, fixed-frequency boost converter designed for high integration and high reliability. The IC integrates a 20-V power switch, input/output isolation switch, and power diode. When the output current exceeds the overload limit, the isolation switch of the IC opens up to disconnect the output from the input. This disconnection protects the IC and the input supply. The isolation switch also disconnects the output from the input during shut down to minimize leakage current. When the IC is shutdown, the output capacitor is discharged to a low voltage level by internal diodes. Other protection features include 1.1-A peak overcurrent protection (OCP) at each cycle, output overvoltage protection (OVP), thermal shutdown, and undervoltage lockout (UVLO).
