Texas Instruments
TPS62000SHKK
TPS62000SHKK
Regular price
$69.08 USD
Regular price
Sale price
$69.08 USD
Unit price
per
Couldn't load pickup availability
TPS62000SHKK Texas Instruments - Yeehing Electronics
High Temperature High-Efficiency Step-Down Low Power DC-DC Converter
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 150.985 |
| 100 — 249 | 134.209 |
| 250 — 999 | 110.328 |
| 1,000 + | 69.08 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Switching Voltage Regulators |
| RoHS | Y |
| Mounting Style | SMD/SMT |
| Package / Case | CFP-10 |
| Output Voltage | 0.8 V to 5.5 V |
| Output Current | 300 mA |
| Number of Outputs | 1 Output |
| Input Voltage MAX | 5.5 V |
| Topology | Buck |
| Input Voltage MIN | 2 V |
| Switching Frequency | 750 kHz |
| Minimum Operating Temperature | - 55 C |
| Maximum Operating Temperature | + 210 C |
| Series | TPS62000-HT |
| Packaging | Tube |
| Height | 2.03 mm |
| Input Voltage | 2 V to 5.5 V |
| Length | 6.35 mm |
| Operating Temperature Range | - 55 C to + 210 C |
| Product | Voltage Regulators |
| Type | Voltage Converter |
| Width | 6.35 mm |
| Brand | Texas Instruments |
| Load Regulation | 0.6 % |
| Operating Supply Current | 50 uA |
| Product Type | Switching Voltage Regulators |
| Factory Pack Quantity | 1 |
| Subcategory | PMIC - Power Management ICs |
For more information, please refer to datasheet
Documents
| TPS62000SHKK Datasheet |
More Information
The TPS62000 device is a low-noise synchronous step-down dc-dc converter that is ideally suited for systems powered from a 1-cell Li-ion battery or from a 2- to 3-cell NiCd, NiMH, or alkaline battery. The TPS62000 operates typically down to an input voltage of 1.8 V, with a specified minimum input voltage of 2 V.
