Texas Instruments
TPS62616YFDT
TPS62616YFDT
Regular price
$0.32 USD
Regular price
Sale price
$0.32 USD
Unit price
per
Couldn't load pickup availability
TPS62616YFDT Texas Instruments - Yeehing Electronics
350-mA, 6-MHz, 2.15Vout High Efficiency Step-Down Converter
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 1.012 |
| 100 — 249 | 0.836 |
| 250 — 999 | 0.601 |
| 1,000 + | 0.32 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Switching Voltage Regulators |
| RoHS | Y |
| Mounting Style | SMD/SMT |
| Package / Case | DSBGA-6 |
| Output Voltage | 2.15 V |
| Output Current | 350 mA |
| Number of Outputs | 1 Output |
| Input Voltage MAX | 5.5 V |
| Topology | Buck |
| Input Voltage MIN | 2.3 V |
| Switching Frequency | 6 MHz |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 85 C |
| Series | TPS62616 |
| Packaging | Reel |
| Input Voltage | 2.3 V to 5.5 V |
| Operating Temperature Range | - 40 C to + 85 C |
| Product | Voltage Regulators |
| Type | Voltage Converter |
| Brand | Texas Instruments |
| Shutdown | Shutdown |
| Load Regulation | - 0.0002 % / mA |
| Operating Supply Current | 31 uA |
| Product Type | Switching Voltage Regulators |
| Factory Pack Quantity | 250 |
| Subcategory | PMIC - Power Management ICs |
| Supply Voltage - Min | 2.3 V |
| Unit Weight | 0.000060 oz |
For more information, please refer to datasheet
Documents
| TPS62616YFDT Datasheet |
More Information
The TPS6261x device is a high-frequency synchronous step-down dc-dc converter optimized for battery-powered portable applications. Intended for low-power applications, the TPS6261x supports up to 350-mA load current, and allows the use of low cost chip inductor and capacitors.
