Texas Instruments
TPS62650TYFFRQ1
TPS62650TYFFRQ1
Regular price
$0.47 USD
Regular price
Sale price
$0.47 USD
Unit price
per
Couldn't load pickup availability
TPS62650TYFFRQ1 Texas Instruments - Yeehing Electronics
Automotive 2.3V to 5.5V, 6MHz Fixed Frequency 800mA Buck Converter
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 1.364 |
| 100 — 249 | 1.195 |
| 250 — 999 | 0.838 |
| 1,000 + | 0.47 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Switching Voltage Regulators |
| RoHS | Y |
| Mounting Style | SMD/SMT |
| Package / Case | DSBGA-9 |
| Output Voltage | 0.75 V to 1.4375 V |
| Output Current | 800 mA |
| Number of Outputs | 1 Output |
| Input Voltage MAX | 5.5 V |
| Topology | Buck |
| Input Voltage MIN | 2.3 V |
| Switching Frequency | 6 MHz |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 105 C |
| Qualification | AEC-Q100 |
| Series | TPS62650-Q1 |
| Packaging | Reel |
| Input Voltage | 2.3 V to 5.5 V |
| Operating Temperature Range | - 40 C to + 105 C |
| Product | Voltage Regulators |
| Type | Voltage Converter |
| Brand | Texas Instruments |
| Operating Supply Current | 38 uA |
| Product Type | Switching Voltage Regulators |
| Factory Pack Quantity | 3000 |
| Subcategory | PMIC - Power Management ICs |
| Unit Weight | 0.000071 oz |
For more information, please refer to datasheet
Documents
| TPS62650TYFFRQ1 Datasheet |
More Information
The TPS62650-Q1 device is a high-frequency synchronous step-down dc-dc converter optimized for battery-powered portable applications. Intended for low-power applications, the TPS62650-Q1 supports up to 800-mA load current and allows the use of small, low-cost inductors and capacitors.
