TPS62671YFDR Texas Instruments - Yeehing Electronics

500-mA, 6-MHz High-Efficiency Step-Down Converter, Vout=1.8V

Pricing (USD)

Quantity	Unit Price
1 — 99	0.936
100 — 249	0.773
250 — 999	0.556
1,000 +	0.25

The above prices are for reference only.

Specifications

Manufacturer	Texas Instruments
Product Category	Switching Voltage Regulators
RoHS	Y
Mounting Style	SMD/SMT
Package / Case	DSBGA-6
Output Voltage	1.8 V
Output Current	500 mA
Number of Outputs	1 Output
Input Voltage MAX	4.8 V
Topology	Buck
Input Voltage MIN	2.3 V
Switching Frequency	6 MHz
Minimum Operating Temperature	- 40 C
Maximum Operating Temperature	+ 85 C
Series	TPS62671
Packaging	Reel
Input Voltage	2.3 V to 4.8 V
Operating Temperature Range	- 40 C to + 85 C
Product	Voltage Regulators
Type	Voltage Converter
Brand	Texas Instruments
Load Regulation	-0.00045 %/mA
Operating Supply Current	17 uA
Product Type	Switching Voltage Regulators
Factory Pack Quantity	3000
Subcategory	PMIC - Power Management ICs
Unit Weight	0.000060 oz

For more information, please refer to datasheet

Documents

TPS62671YFDR Datasheet

More Information

The TPS6267x devices are high-frequency synchronous step-down dc-dc converters optimized for small battery-powered applications. Intended for low-power applications, the TPS6267x supports up to 650-mA load current and allows the use of low cost chip inductor and capacitors.
