TPS63010YFFR


YeeHing #: Y012-TPS63010YFFR
Inventory: 7600

Feel free to reach out to us for more information.
Click the button below to unveil exclusive discounts and delightful surprises.

Description

TPS63010YFFR Texas Instruments - Yeehing Electronics

High Efficient Single Inductor Buck-Boost Converter with 2-A Switches

Pricing (USD)

Quantity Unit Price
1 — 99 1.608
100 — 249 1.328
250 — 999 0.954
1,000 + 0.50

The above prices are for reference only.

Specifications

Manufacturer Texas Instruments
Product Category Switching Voltage Regulators
RoHS Y
Mounting Style SMD/SMT
Package / Case DSBGA-20
Output Voltage 1.2 V to 5.5 V
Output Current 2.2 A
Number of Outputs 1 Output
Input Voltage MAX 5.5 V
Topology Boost, Buck
Input Voltage MIN 2 V
Switching Frequency 2.4 MHz
Minimum Operating Temperature - 40 C
Maximum Operating Temperature + 85 C
Series TPS63010
Packaging Reel
Height 0.4 mm
Input Voltage 2 V to 5.5 V
Length 2.65 mm
Operating Temperature Range - 40 C to + 85 C
Product Voltage Regulators
Type Switching Regulator
Width 2.25 mm
Brand Texas Instruments
Development Kit TPS63010EVM-235
Load Regulation 0.5 %
Operating Supply Current 40 uA
Product Type Switching Voltage Regulators
Factory Pack Quantity 3000
Subcategory PMIC - Power Management ICs
Unit Weight 0.000162 oz

For more information, please refer to datasheet

Documents

TPS63010YFFR Datasheet

More Information

The TPS6301x devices provide a power supply solution for products powered by either a two-cell or three-cell alkaline, NiCd or NiMH battery, or a one-cell Li-Ion or Li-polymer battery. Output currents can go as high as 1200 mA while using a single-cell Li-Ion or Li-Polymer Battery, and discharge it down to 2.5 V or lower. The buck-boost converter is based on a fixed-frequency, pulse-width-modulation (PWM) controller using synchronous rectification to obtain maximum efficiency. At low load currents, the converter enters power save mode to maintain high efficiency over a wide load current range. The power save mode can be disabled, forcing the converter to operate at a fixed switching frequency. The maximum average current in the switches is limited to a typical value of 2200 mA. The output voltage is programmable using an external resistor divider, or is fixed internally on the chip. The converter can be disabled to minimize battery drain. During shutdown, the load is disconnected from the battery. The device is packaged in a 20-pin DSBGA package measuring 2.126 mm × 1.922 mm (YFF).
