TPS65135RTER Texas Instruments - Yeehing Electronics
Split-Rail Converter, Single-Inductor, Multiple-Output (SIMO) Regulator
Pricing (USD)
Quantity | Unit Price |
1 — 99 | 1.6 |
100 — 249 | 1.402 |
250 — 999 | 0.983 |
1,000 + | 0.55 |
The above prices are for reference only.
Specifications
Manufacturer | Texas Instruments |
Product Category | Switching Voltage Regulators |
RoHS | Y |
Mounting Style | SMD/SMT |
Package / Case | WQFN-16 |
Output Voltage | 3 V to 6 V, - 2.5 V to - 7 V |
Output Current | 80 mA |
Number of Outputs | 2 Output |
Input Voltage MAX | 5.5 V |
Topology | Boost, Buck |
Input Voltage MIN | 2.5 V |
Switching Frequency | 1 MHz |
Minimum Operating Temperature | - 40 C |
Maximum Operating Temperature | + 85 C |
Series | TPS65135 |
Packaging | Reel |
Input Voltage | 2.5 V to 5.5 V |
Operating Temperature Range | - 40 C to + 85 C |
Product | Voltage Regulators |
Type | LCD Bias |
Brand | Texas Instruments |
Development Kit | TPS65135EVM-265 |
Moisture Sensitive | Yes |
Operating Supply Current | 7 mA |
Product Type | Switching Voltage Regulators |
Factory Pack Quantity | 3000 |
Subcategory | PMIC - Power Management ICs |
Unit Weight | 0.001411 oz |
For more information, please refer to datasheet
Documents
TPS65135RTER Datasheet |
More Information
The TPS65135 device is a high-efficiency split-rail power supply. Thanks to its single-inductor, multiple-output (SIMO) topology, the converter uses very few external components. The device operates with a buck-boost topology and generates positive and negative output voltages above or below the input supply voltage. The SIMO topology achieves excellent line and load regulation, which is necessary, for example, to avoid disturbance of a mobile phone display as a result of input voltage variations that occur during transmit periods in mobile communication systems. The device can also be used as a general-purpose split-rail supply as long as the output current mismatch between the rails is less than 50%.
