TPS65165RSBR Texas Instruments - Yeehing Electronics
4-CH LCD Bias w/ Fully Int. Pos. Charge Pump, 3.3V LDO Contr., 0.96A Min. Boost Ilim & Fault Detect
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 3.2 |
| 100 — 249 | 2.804 |
| 250 — 999 | 1.966 |
| 1,000 + | 1.27 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Power Management Specialized - PMIC |
| RoHS | Y |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 85 C |
| Mounting Style | SMD/SMT |
| Package / Case | WQFN-40 |
| Type | LCD Bias,VCOM |
| Packaging | Reel |
| Height | 0.75 mm |
| Length | 5 mm |
| Series | TPS65165 |
| Width | 5 mm |
| Brand | Texas Instruments |
| Development Kit | TPS65165EVM-233 |
| Moisture Sensitive | Yes |
| Pd - Power Dissipation | 1.8 W |
| Product Type | Power Management Specialized - PMIC |
| Factory Pack Quantity | 3000 |
| Subcategory | PMIC - Power Management ICs |
| Unit Weight | 0.001764 oz |
For more information, please refer to datasheet
Documents
| TPS65165RSBR Datasheet |
More Information
The TPS65165 is a Compact LCD Bias IC with 3 high-speed operational amplifiers for gamma correction and/or VCOM supply. The device generates all 3 voltage rails for TFT-LCD displays (Vs, VGL and VGH). The device incorporates a high-voltage switch that can be controlled by a logic signal from the timing controller (TCON) to provide the gate-voltage modulation for VGH. If this function is not required, the CTRL pin can be tied high.
