TPS65563ARGTR Texas Instruments - Yeehing Electronics

Integrated photo flash charger and IGBT driver with 2A Iout

Pricing (USD)

Quantity	Unit Price
1 — 99	1.546
100 — 249	1.277
250 — 999	0.917
1,000 +	0.48

The above prices are for reference only.

Specifications

Manufacturer	Texas Instruments
Product Category	Power Management Specialized - PMIC
RoHS	Y
Output Voltage Range	- 0.6 V to + 6 V
Input Voltage Range	1.4 V to 12 V
Input Current	2 mA
Minimum Operating Temperature	- 35 C
Maximum Operating Temperature	+ 85 C
Mounting Style	SMD/SMT
Package / Case	VQFN-16
Type	Photo Flash Charger
Packaging	Reel
Application	Cameras
Operating Temperature Range	- 35 C to + 85 C
Product	Photo-Flash Drivers
Series	TPS65563A
Brand	Texas Instruments
Moisture Sensitive	Yes
Operating Supply Current	2 mA
Operating Supply Voltage	1.4 V to 12 V
Pd - Power Dissipation	2.11 W
Product Type	Power Management Specialized - PMIC
Factory Pack Quantity	3000
Subcategory	PMIC - Power Management ICs
Unit Weight	0.000850 oz

For more information, please refer to datasheet

Documents

TPS65563ARGTR Datasheet

More Information

The TPS65563A offers a complete solution for a charging photo flash capacitor and flashing xenon tube with an insulated gate bipolar transfer (IGBT) driver. This device has an integrated voltage reference, power switch (SW), comparators for peak current detection/power SW turnon detection/charge complete detection, an IGBT driver, and control logics for charging applications/driving IGBT applications.
