TPS92511DDAR Texas Instruments - Yeehing Electronics
500mA 30W Anode Capable constant current buck LED Dvr
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 0.876 |
| 100 — 249 | 0.723 |
| 250 — 999 | 0.52 |
| 1,000 + | 0.27 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | LED Lighting Drivers |
| RoHS | Y |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 125 C |
| Mounting Style | SMD/SMT |
| Package / Case | SO-PowerPad-8 |
| Series | TPS92511 |
| Packaging | Reel |
| Features | Adjustable Switch Frequency, Enable/Shutdown, Integrated Switch, Thermal Shutdown |
| Operating Temperature Range | - 40 C to + 125 C |
| Brand | Texas Instruments |
| Dimming | Analog,PWM |
| Moisture Sensitive | Yes |
| Product Type | LED Lighting Drivers |
| Factory Pack Quantity | 2500 |
| Subcategory | Driver ICs |
| Unit Weight | 0.002822 oz |
For more information, please refer to datasheet
Documents
| TPS92511DDAR Datasheet |
More Information
The TPS92511 is an easy to use 65V constant current buck converter for driving a single LED string with current up to 0.5A and efficiency up to 95%. Only 5 external components are required for basic operation and single layer PCB layout is feasible because of the integration of a N-MOSFET, no external current sensing resistor, no external compensation and the proper terminal assignment. A high-value external resistor programs the LED current so that fine tuning of the LED current can be achieved. Another high-value external resistor programs a constant switching frequency from 50kHz to 500kHz. EMI design becomes easier as a result of constant switching frequency. The TPS92511 provides a wide input voltage range from 4.5V to 65V. By adding simple external circuits, the device can handle applications with even higher input voltages.
