Description
TPSM53604RDAR Texas Instruments - Yeehing Electronics
36-V, 4-A step-down power module in small 5.5 x 5 x 4-mm Enhanced HotRod™ QFN with simple footprint
Pricing (USD)
Quantity | Unit Price |
1 — 99 | 8.217 |
100 — 249 | 7.178 |
250 — 999 | 5.534 |
1,000 + | 3.46 |
The above prices are for reference only.
Specifications
For more information, please refer to datasheet
Documents
TPSM53604RDAR Datasheet |
More Information
The TPSM53604 power module is a highly integrated 4-A power solution that combines a 36-V input, step-down, DC/DC converter with power MOSFETs, a shielded inductor, and passives in a thermally-enhanced QFN package. The 5-mm x 5.5-mm x 4-mm, 15-pin package uses Enhanced HotRod QFN technology for improved thermal performance, small footprint, and low EMI. The package footprint has all pins accessible from the perimeter and a single large thermal pad for simple layout and easy handling in manufacturing.
