TS3A225ERTER Texas Instruments - Yeehing Electronics

100-mΩ audio jack switch with autonomous microphone & ground detection

Pricing (USD)

Quantity	Unit Price
1 — 99	0.694
100 — 249	0.534
250 — 999	0.393
1,000 +	0.20

The above prices are for reference only.

Specifications

Manufacturer	Texas Instruments
Product Category	Analog Switch ICs
RoHS	Y
Number of Switches	2 Switch
Configuration	2 x SPDT
On Resistance - Max	10 Ohms
Switch Voltage - Max	3.3 V
Operating Supply Voltage	2.7 V to 4.5 V
Minimum Operating Temperature	- 40 C
Maximum Operating Temperature	+ 85 C
Mounting Style	SMD/SMT
Package / Case	WQFN-16
Packaging	Reel
Series	TS3A225E
Supply Type	Single Supply
Brand	Texas Instruments
Supply Current - Max	10 uA
Moisture Sensitive	Yes
Product Type	Analog Switch ICs
Factory Pack Quantity	3000
Subcategory	Switch ICs
Supply Voltage - Max	4.5 V
Supply Voltage - Min	2.7 V
Part # Aliases	HPA02141ERTER
Unit Weight	0.002014 oz

For more information, please refer to datasheet

Documents

TS3A225ERTER Datasheet

More Information

The TS3A225E is an audio headset switch device. The device detects the presence of an analog microphone and switches a system analog microphone pin between different connectors in an audio stereo jack. The microphone connection in a stereo connector can be swapped with the ground connection depending on manufacturer. When the TS3A225E detects a certain configuration, the device automatically connects the microphone line to the appropriate pin. The device also reports the presence of an analog microphone on an audio stereo jack.
