TS3A5223RSWR Texas Instruments - Yeehing Electronics
0.45-Ω on-state resistance, 3.3-V, 2:1 (SPDT), 2-channel analog switch with 1-V logic
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 0.451 |
| 100 — 249 | 0.306 |
| 250 — 999 | 0.236 |
| 1,000 + | 0.13 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Analog Switch ICs |
| RoHS | Y |
| Number of Switches | 2 Switch |
| Configuration | 2 x SPDT |
| On Resistance - Max | 600 mOhms |
| Switch Voltage - Max | 3.6 V |
| On Time - Max | 70 ns |
| Off Time - Max | 75 ns |
| Operating Supply Voltage | 1.65 V to 3.6 V |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 85 C |
| Mounting Style | SMD/SMT |
| Package / Case | UQFN-10 |
| Packaging | Reel |
| Series | TS3A5223 |
| Supply Type | Single Supply |
| Brand | Texas Instruments |
| Supply Current - Max | 2 uA |
| Pd - Power Dissipation | 430 mW |
| Product Type | Analog Switch ICs |
| Factory Pack Quantity | 3000 |
| Subcategory | Switch ICs |
| Supply Voltage - Max | 3.6 V |
| Supply Voltage - Min | 1.65 V |
| Unit Weight | 0.000353 oz |
For more information, please refer to datasheet
Documents
| TS3A5223RSWR Datasheet |
More Information
The TS3A5223 is a high-speed 2-channel analog switch with break-before-make and bi-directional signal switching capability. The TS3A5223 can be used as a dual 2:1 multiplexer or a 1:2 dual de-multiplexer.
