TXB0102DCUTG4 Texas Instruments - Yeehing Electronics

2-Bit Bidirectional Voltage-Level Shifter with Auto Direction Sensing and +/-15-kV ESD Protect

Pricing (USD)

Quantity	Unit Price
1 — 99	0.832
100 — 249	0.64
250 — 999	0.471
1,000 +	0.24

The above prices are for reference only.

Specifications

Manufacturer	Texas Instruments
Product Category	Translation - Voltage Levels
RoHS	Y
Propagation Delay Time	7.4 ns
Supply Voltage - Max	3.6 V, 5.5 V
Supply Voltage - Min	1.2 V, 1.65 V
Minimum Operating Temperature	- 40 C
Maximum Operating Temperature	+ 85 C
Mounting Style	SMD/SMT
Package / Case	VSSOP-8
Packaging	Reel
Features	One-Shot Edge Accelerators, Bidirectional
Input Type	CMOS, TTL
Operating Temperature Range	- 40 C to + 85 C
Series	TXB0102
Brand	Texas Instruments
Logic Type	True
Product Type	Translation - Voltage Levels
Factory Pack Quantity	250
Subcategory	Logic ICs
Unit Weight	0.000339 oz

For more information, please refer to datasheet

Documents

TXB0102DCUTG4 Datasheet

More Information

The TXB0102 device is a 2-bit noninverting translator that uses two separate configurable power-supply rails. The A port is designed to track VCCA. VCCA accepts any supply voltage from 1.2 V to 3.6 V. The B port is designed to track VCCB. VCCB accepts any supply voltage from 1.65 V to 5.5 V. This allows for universal low-voltage bidirectional translation between any of the 1.2-V, 1.5-V, 1.8-V, 2.5-V, 3.3-V, and 5-V voltage nodes. VCCA must not exceed VCCB.
