TXS0102DCTR


YeeHing #: Y009-TXS0102DCTR
Inventory: 5200

Feel free to reach out to us for more information.
Click the button below to unveil exclusive discounts and delightful surprises.

Description

TXS0102DCTR Texas Instruments - Yeehing Electronics

2-Bit Bidirectional Voltage-Level Shifter for Open-Drain and Push-Pull Application

Pricing (USD)

Quantity Unit Price
1 — 99 0.47
100 — 249 0.32
250 — 999 0.24
1,000 + 0.15

The above prices are for reference only.

Specifications

Manufacturer Texas Instruments
Product Category Translation - Voltage Levels
RoHS Y
Propagation Delay Time 260 ns
Supply Voltage - Max 3.6 V, 5.5 V
Supply Voltage - Min 1.65 V, 2.3 V
Minimum Operating Temperature - 40 C
Maximum Operating Temperature + 85 C
Mounting Style SMD/SMT
Package / Case SM-8
Packaging Reel
Features One-Shot Edge Accelerators, Bidirectional
Operating Temperature Range - 40 C to + 85 C
Series TXS0102
Brand Texas Instruments
Logic Family TXS01
Logic Type True
Product Type Translation - Voltage Levels
Factory Pack Quantity 3000
Subcategory Logic ICs
Unit Weight 0.000825 oz

For more information, please refer to datasheet

Documents

TXS0102DCTR Datasheet



More Information

This two-bit non-inverting translator is a bidirectional voltage-level translator and can be used to establish digital switching compatibility between mixed-voltage systems. It uses two separate configurable power-supply rails, with the A ports supporting operating voltages from 1.65 V to 3.6 V while it tracks the VCCA supply, and the B ports supporting operating voltages from 2.3 V to 5.5 V while it tracks the VCCB supply. This allows the support of both lower and higher logic signal levels while providing bidirectional translation capabilities between any of the 1.8-V, 2.5-V, 3.3-V, and 5-V voltage nodes.
