TXS03121DRLR
TXS03121DRLR
Couldn't load pickup availability
TXS03121DRLR Texas Instruments - Yeehing Electronics
Micropower, single comparator
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 0.869 |
| 100 — 249 | 0.669 |
| 250 — 999 | 0.492 |
| 1,000 + | 0.25 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Translation - Voltage Levels |
| RoHS | Y |
| Supply Voltage - Max | 5.5 V |
| Supply Voltage - Min | 2.5 V |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 85 C |
| Mounting Style | SMD/SMT |
| Package / Case | SOT-5X3-6 |
| Packaging | Reel |
| Operating Temperature Range | - 40 C to + 85 C |
| Series | TXS03121 |
| Brand | Texas Instruments |
| Operating Supply Current | 8 uA |
| Product Type | Translation - Voltage Levels |
| Factory Pack Quantity | 4000 |
| Subcategory | Logic ICs |
| Unit Weight | 0.000229 oz |
For more information, please refer to datasheet
Documents
| TXS03121DRLR Datasheet |
More Information
The TXS03121 is a comparator designed for battery monitoring applications. It can be operated with a voltage of 2.5 V to 5.5 V. The reference voltage is applied to the IN terminal, whereas the voltage to be monitored is connected to +IN. When the voltage at +IN is greater than the voltage at IN, the output FET is turned On. When the voltage at +IN is less than the voltage at IN, the output FET is turned Off. The source (S) of the output FET can be connected to 1.1 V to 3.6 V, which allows the output signal to be level translated to another voltage value. The voltage at V+ must be greater than or equal to the voltage at S. The voltage at S must be greater than or equal to the voltage at D (V+ ≥ VS ≥ VD).
