UC1526J883B Texas Instruments - Yeehing Electronics
Regulating Pulse Width Modulator
Pricing (USD)
Quantity | Unit Price |
1 — 99 | 22.564 |
100 — 249 | 19.71 |
250 — 999 | 15.197 |
1,000 + | 9.52 |
The above prices are for reference only.
Specifications
For more information, please refer to datasheet
Documents
UC1526J883B Datasheet |
More Information
The UC1526 is a high performance monolithic pulse width modulator circuit designed for fixed-frequency switching regulators and other power control applications. Included in an 18-pin dual-in-line package are a temperature compensated voltage reference, sawtooth oscillator, error amplifier, pulse width modulator, pulse metering and setting logic, and two low impedance power drivers. Also included are protective features such as soft-start and under-voltage lockout, digital current limiting, double pulse inhibit, a data latch for single pulse metering, adjustable deadtime, and provision for symmetry correction inputs. For ease of interface, all digital control ports are TTL and B-series CMOS compatible. Active LOW logic design allows wired-OR connections for maximum flexibility. This versatile device can be used to implement single-ended or push-pull switching regulators of either polarity, both transformerless and transformer coupled. The UC1526 is characterized for operation over the full military temperature range of -55°C to +125°C. The UC2526 is characterized for operation from -25°C to +85°C, and the UC3526 is characterized for operation from 0° to +70°C.
