UCC25800AQDGNRQ1 Texas Instruments - Yeehing Electronics

Ultra-low EMI transformer driver for isolated bias supplies

Pricing (USD)

Quantity	Unit Price
1 — 99	2.195
100 — 249	1.813
250 — 999	1.302
1,000 +	0.69

The above prices are for reference only.

Specifications

For more information, please refer to datasheet

Documents

UCC25800AQDGNRQ1 Datasheet

More Information

The UCC25800-Q1 ultra-low EMI transformer driver integrates the switching power stage, the control, and the protection circuits to simplify isolated bias supply designs. It allows the design to utilize a transformer with higher leakage inductance, but much smaller parasitic primary-to-secondary capacitance. This low-capacitance transformer design enables an order of magnitude reduction in the common-mode current injection through the bias transformer. This makes the transformer driver an ideal solution for the isolated bias supply in various automotive applications to minimize the EMI noise caused by the high-speed switching devices. The soft-switching feature further reduces the EMI noise.
