UCC27512DRSR Texas Instruments - Yeehing Electronics
4-A/8-A single-channel gate driver with 5-V UVLO and split outputs in SON package
Pricing (USD)
| Quantity | Unit Price |
| 1 — 99 | 0.887 |
| 100 — 249 | 0.682 |
| 250 — 999 | 0.502 |
| 1,000 + | 0.25 |
The above prices are for reference only.
Specifications
| Manufacturer | Texas Instruments |
| Product Category | Gate Drivers |
| RoHS | Y |
| Product | MOSFET Gate Drivers |
| Type | Low Side |
| Mounting Style | SMD/SMT |
| Package / Case | WSON-6 |
| Output Current | 8 A |
| Rise Time | 9 ns |
| Fall Time | 7 ns |
| Supply Voltage - Min | 4.5 V |
| Supply Voltage - Max | 18 V |
| Operating Supply Current | 4 A |
| Minimum Operating Temperature | - 40 C |
| Maximum Operating Temperature | + 140 C |
| Series | UCC27512 |
| Packaging | Reel |
| Features | Hysteretic Logic |
| Operating Temperature Range | - 40 C to + 140 C |
| Technology | Si |
| Brand | Texas Instruments |
| Logic Type | TTL |
| Moisture Sensitive | Yes |
| Operating Supply Voltage | 4.5 V to 18 V |
| Product Type | Gate Drivers |
| Factory Pack Quantity | 3000 |
| Subcategory | PMIC - Power Management ICs |
| Unit Weight | 0.000342 oz |
For more information, please refer to datasheet
Documents
| UCC27512DRSR Datasheet |
More Information
The UCC27511 and UCC27512 single-channel, high-speed, low-side gate-driver device can effectively drive MOSFET and IGBT power switches. Using a design that inherently minimizes shoot-through current, UCC27511 and UCC27512 are capable of sourcing and sinking high peak-current pulses into capacitive loads offering rail-to-rail drive capability and extremely small propagation delay, typically 13 ns.
