UCC28251RGPR Texas Instruments - Yeehing Electronics
Advanced half-bridge/full-bridge PWM controller with pre-bias operation for offline applications
Pricing (USD)
Quantity | Unit Price |
1 — 99 | 3.171 |
100 — 249 | 2.779 |
250 — 999 | 1.948 |
1,000 + | 0.91 |
The above prices are for reference only.
Specifications
Manufacturer | Texas Instruments |
Product Category | Switching Controllers |
RoHS | Y |
Topology | Forward |
Number of Outputs | 4 Output |
Switching Frequency | 40 kHz to 1000 kHz |
Duty Cycle - Max | 100 % |
Output Voltage | 3.25 V |
Output Current | 200 mA |
Minimum Operating Temperature | - 40 C |
Maximum Operating Temperature | + 125 C |
Mounting Style | SMD/SMT |
Package / Case | QFN-20 |
Packaging | Reel |
Operating Temperature Range | - 40 C to + 125 C |
Series | UCC28251 |
Type | Voltage Mode PWM Controllers |
Brand | Texas Instruments |
Fall Time | 8 ns |
Moisture Sensitive | Yes |
Operating Supply Current | 2 mA |
Operating Supply Voltage | 12 V |
Product Type | Switching Controllers |
Rise Time | 8 ns |
Factory Pack Quantity | 3000 |
Subcategory | PMIC - Power Management ICs |
Unit Weight | 0.002469 oz |
For more information, please refer to datasheet
Documents
UCC28251RGPR Datasheet |
More Information
The UCC28251 PWM controller is designed for high power density applications that may have stringent prebiased startup requirements. The UCC28251s integrated synchronous rectifier control outputs target high efficiency and high performance topologies such as half-bridge, full-bridge, interleaved forward, and push-pull. The UCC27210 half bridge drivers and UCC2752x MOSFET drivers used in conjunction with the UCC28251 provide a complete power converter solution.
