UCC28740D Texas Instruments - Yeehing Electronics

Constant-Voltage, Constant-Current (CVCC) Flyback controller with Secondary Side Regulation (SSR)

Pricing (USD)

Quantity	Unit Price
1 — 99	1.012
100 — 249	0.836
250 — 999	0.601
1,000 +	0.32

The above prices are for reference only.

Specifications

Manufacturer	Texas Instruments
Product Category	Switching Controllers
RoHS	Y
Topology	Flyback
Switching Frequency	0.17 kHz to 100 kHz
Duty Cycle - Max	99 %
Minimum Operating Temperature	- 40 C
Maximum Operating Temperature	+ 125 C
Mounting Style	SMD/SMT
Package / Case	SOIC-7
Packaging	Reel
Operating Temperature Range	- 40 C to + 125 C
Series	UCC28740
Type	Current Mode PWM Controllers
Brand	Texas Instruments
Operating Supply Voltage	8.1 V to 35 V
Product Type	Switching Controllers
Factory Pack Quantity	2500
Subcategory	PMIC - Power Management ICs
Unit Weight	0.008960 oz

For more information, please refer to datasheet

Documents

UCC28740D Datasheet

More Information

The UCC28740 isolated-flyback power-supply controller provides Constant-Voltage (CV) using an optical coupler to improve transient response to large-load steps. Constant-Current (CC) regulation is accomplished through Primary-Side Regulation (PSR) techniques. This device processes information from opto-coupled feedback and an auxiliary flyback winding for precise high-performance control of output voltage and current.
